Modular design with standard interfaces
Safety circuit design to ensure bidirectional safety between personnel and equipment
Intelligent scheduling seamlessly integrates with MES, WMS, ERP, etc
High precision docking production line, capable of automatic hooking and unhooking.
Efficient towing, capable of towing 4-6 trailers at a time.
High safety, 360 degree laser protection, multiple safety barriers.
Flexible intelligence, fast deployment and import, saving manpower.
Model | Product model | ANR-T30 | ANR-T50 | |
Basic parameters | Rated traction load kg | 3000 | 5000 | |
Navigation method | SLAM | |||
Size | 1259*848*1766mm(Excluding traction pins) | |||
Weight kg | 900 | 1100 | ||
Minimum channel mm | 2500 | |||
Height of towing hook mm | 280~330(Customizable) | |||
Motion parameters | Max Climb Capability ° | 8/6(Full load climbing speed1km/h) | ||
Maximum driving speed/forward km/h | Full load | 4 | ||
Empty load | 6.4 | |||
Navigation | Navigation accuracy mm | ±10 | ||
Angle accuracy° | ±1 | |||
Protection | Laser obstacle avoidance | Front safety laser×2 | ||
Anti-collision strip | Front anti-collision strip | |||
Sound and light alarm | Standard configuration | |||
Emergency stop switch | Standard configuration (quantity 2) | |||
Power and performance | Battery type | Lithium iron phosphate | ||
Battery capacity/voltage Ah/V | 240Ah/24V | 300Ah/24V | ||
Continuous working endurance H | 8 | |||
Charging method | Manual/automatic charging | |||
Number of charge discharge cycles/full charge discharge | 2000 times (20% attenuation) | |||
other | control mode | Manual/Automatic |
