Forward/backward/sideways/spin in place
Especially suitable for narrow channel handling operations
Standard chassis, customizable design
Laser SLAM/ QR Code navigation/Composite navigation
360-degree security protection
Forward/backward/sideways/spin in place
Especially suitable for narrow channel handling operations
Standard chassis, customizable design
Laser SLAM/ QR Code navigation/Composite navigation
360-degree security protection
Model | ANR-HD10 | ANR-HD20 | |
Payload (kg) | 1000 | 2000 | |
Navigation type | Laser SLAM | ||
AGV dimension (mm) | 1700*1500*1520 | 2000*1700*1520 | |
Weight kg | 1200 | 1500 | |
Jacking height (mm) | 200~900（可选） | ||
Jacking time (s) | 2196 | 2554 | |
Rotation diameter (mm) | Standard | ||
Max. climbing ability (°) | 3 | ||
| Max. acceleration (m/s2) | 0.5 | ||
Traveling speed (m/s) | 1.2 | ||
| Positioning accuracy (mm) | ±10 | ||
| Angular accuracy (°) | ±1 | ||
| Laser obstacle avoidance | safety laser ×1 | ||
| Bumper strip | Front/rear C-shaped bumper strip | ||
| Audible alarm | Standard | ||
| Emergency stop button | Standard (X4) | ||
| Battery type | lithium iron phosphate | ||
| Battery volume (Ah/V) | 36Ah/48V | 66Ah/48V | |
| Charging time (H) | 2 | ||
| Endurance time (H) | 8 | ||
| Charging type | Manual/Automatic | ||
| Charge/discharge cycle | 2000times（15% attenuation） | ||
| Control type | Manual/Automatic | ||
