360-degree omnidirectional movement such as lateral movement and oblique movement
Can adapt to operating scenarios under high-strict environments, such as narrow aisles or insufficient rotating space, etc.
Modular design, standard interface
Safety circuit design to ensure two-way safety between people and equipment
Intelligent scheduling seamlessly connects with MES, WMS, ERP, etc.
Common applications: Used for walking in scenes where AGV rotation space is insufficient
Product Model | A06 | A10 | ||
Basic Performance | Load kg | 600 | 1000 | |
Navigation Mode | Laser SLAM / QR code / composite navigation | |||
Size mm | 1000*600*300 | 1200*760*300 | ||
Weight kg | 240 | 300 | ||
Lifting mm | / | |||
Motion Performance | Maximum Climbing Fully loaded/Unloaded︒ | 3 | ||
Maximum Acceleration m/s2 | 0.4 | |||
Maximum driving speed m/s | Fully loaded | 0.85 | ||
Unloaded | 1 | |||
Positioning and navigation | Position Accuracy mm | ±10 | ||
Angle Accuracy ° | ±1 | |||
Protection | Laser Obstacle Avoidance | Safety Laser×2,360°full coverage | ||
Bumper Strip | Four-sided Anti-collision Strip | |||
Audible Alarm | Standard | |||
Emergency stop switch | Standard(Quantity 4) | |||
Power and Performance | Battery Type | Lithium Iron Phosphate | ||
Battery Capacity/Voltage | 36Ah/48V | 40Ah/48V | ||
Charging Time H | 1.2 | |||
Endurance H | 8 | |||
Charging Mode | Manual/Automatic | |||
Charge and Discharge Times | 2000 times (15% attenuation) | |||
other | Control Mode | Manual / Auto |
